MINOPLEX FEATURES
Tear Resistant
High Flexibility
Low Elongation
High Tensile Strength
Waterproof
Flame Retardant
Antifungal Protection
Excellent Weldability
MINOPLEX Ripstop is a specialized laminated PVC fabric developed for mine ventilation ducts and demanding underground environments.
MINOPLEX features antifungal and flame-retardant properties for enhanced protection in demanding applications.
Selected Colors
Available in selected colors commonly used for mining applications.
Ripstop Reinforcement
High-tenacity yarn reinforcement helps limit tearing and prevents damage from spreading through the fabric.
MINOPLEX 12x12 500 g/m² RF SPECIFICATIONS
Composition
Threads/Denier 12x12/1000x1000 RIPSTOP
31LK0516
ROLL SIZE
- 100 m. / 109.36 yd.
- 1.55 m. / 61.02 in.
- 77.50kg/ 170.86 lb.
- 0.300m. / 11.811 in.
TECHNICAL DATA
- 500±17 g/m2 15±0.5 oz/sqyd
- L.: >35lbf / >77lbf T.:>30lbf / >66lbf
- L & T: < 30%
- 0.457±0.025mm 0.01808±0.001in
- Does Not Peel
- L.: >105 Kgf/in / T.: >231 lbf/in
- 152.4mm >6in
- 1 seg.
CERTIFICATIONS
MINOPLEX COLORS
*NOTE*: The colors shown may vary slightly due to your screen resolution and settings.
**The images presented on this website are for illustrative purposes only and are not the property of Oplex S.A. de C.V.*
***In order to provide a better experience and maintain transparent communication, our website and digital catalogs include images of finished products solely as visual references to illustrate some of the many applications of our materials.
All trademarks, photographs, and designs belong to their respective owners and are displayed for illustrative purposes only.
Oplex manufactures and sells plastic fabrics and tarpaulins; it does not sell the finished products shown in these images, nor does it claim ownership or authorship of their designs.
We appreciate your understanding and respect for the intellectual property rights of all parties involved.
- Mine Ventilation Ducts
